Vitruvio: Conditional Variational Autoencoder (CVAE) to Generate Building Meshes via Single Perspective Sketches
Alberto Tono1,2, Heyaojing Huang1, Ashwin Agrawal1, Martin Fischer1,
1Stanford University, 2Computational Design Institute
Paper Publications
Highlights
- We introduced learning-based method for single perspective sketch-to-3D applications in the Architecture Engineering and Construction (AEC) industry.
- We adapted a previous state-of-the-art Conditional Variational Autoencoder (Occupancy Network) to scalable datasets.
- We showed qualitatively and quantitatively how the building orientation affects the reconstruction.
Abstract
Today’s architectural engineering and construction (AEC) software require a learning curve to generate a three-dimension building representation. This limits the ability to quickly validate the volumetric implications of an initial design idea communicated via a single sketch. Allowing designers to translate a single sketch to a 3D building will enable owners to instantly visualize 3D project information without the cognitive load required. If previous state-of-the-art (SOTA) data-driven methods for single view reconstruction (SVR) showed outstanding results in the reconstruction process from a single image or sketch, they lacked specific applications, analysis, and experiments in the AEC. Therefore, this research addresses this gap, introducing the first deep learning method focused only on buildings that aim to convert a single sketch to a 3D building mesh: Vitruvio. Vitruvio adapts Occupancy Network for SVR tasks on a specific building dataset (Manhattan 1K). This adaptation brings two main improvements. First, it accelerates the inference process by more than 26% (from 0.5s to 0.37s). Second, it increases the reconstruction accuracy (measured by the Chamfer Distance) by 18%. During this adaptation in the AEC domain, we evaluate the effect of the building orientation in the learning procedure since it constitutes an important design factor. While aligning all the buildings to a canonical pose improved the overall quantitative metrics, it did not capture fine-grain details in more complex building shapes (as shown in our qualitative analysis). Finally, Vitruvio outputs a 3D-printable building mesh with arbitrary topology and genus from a single perspective sketch, providing a step forward to allow owners and designers to communicate 3D information via a 2D, effective, intuitive, and universal communication medium: the sketch.
Presentation
Alignment Algorithm
This orientation algorithm aligns buildings to their canonical poses while keeping track of the true north (N) position. Step 2 extracts the Oriented Bounding Box (OBB), and its main axis (𝐼𝑦) is used to perform the orientation in steps 3 and 4. Since we need to keep track of the orientation angle, we create a convention for clockwise and counterclockwise rotations. In step 6, we save the rotation angle for each building in a .txt file named ’Rotation Tracker.txt’.
Dataset
Dataset, Weights Request & Contribution Form [5GB]
Dataset Split [26kb]
Contact Information
- Alberto Tono : alberto.tono@cd.institute or atono@stanford.edu
Cite
@article{TONO2024105498,
title = {Vitruvio: Conditional variational autoencoder to generate building meshes via single perspective sketches},
journal = {Automation in Construction},
volume = {166},
pages = {105498},
year = {2024},
issn = {0926-5805},
doi = {https://doi.org/10.1016/j.autcon.2024.105498},
url = {https://www.sciencedirect.com/science/article/pii/S0926580524002346},
author = {Alberto Tono and Heyaojing Huang and Ashwin Agrawal and Martin Fischer},
keywords = {Artificial intelligence, Neural-aided design, Deep generative design, Deep generative modeling, Conditional variational autoencoder, Sketch-based modeling},
abstract = {}
}
